PCBasic’s PCB Assembly Capabilities | One-Stop PCBA Manufacturing & Intelligent Factory

PCBasic integrates precise manufacturing with digital intelligence, ensuring that every customer receives products that are fast, stable, and reliable. PCBasic has advanced intelligent production lines that can provide customers with high-efficiency, high-precision, and highly cost-competitive one-stop services from PCB manufacturing to PCB assembly.

Our factory has a complete production system covering PCB manufacturing, SMT soldering, DIP assembly, electrical testing, functional testing, conformal coating, and box-build assembly. We also have an independently developed MES + ERP + CRM + IoT digital management platform that enables real-time monitoring and traceability management throughout the entire process from document review to production and shipment.

Here are some of our PCB assembly capability introductions. Of course, our PCB assembly capabilities do not only include the items listed above. PCBasic sincerely invites you to jointly pay attention to the constantly updated equipment and processes and jointly maintain the industry-leading level. If you are unsure whether we can serve your project, please contact us via JS@pcbasic.com. Our engineering team will reply within 24 hours, assess the feasibility, and provide professional technical support.

Item	Item Name	PCBA Capability
1	Lead Time	Our assembly lead time ranges from 24 hours for quick-turn prototypes to 2–3 weeks for complex multi-layer production. Thanks to our digital MES system and fully automated production lines, every process. from engineering review to shipment, is traceable and efficiently scheduled to ensure on-time delivery.
2	Parts Source	Consigned/Kitted You may provide all components along with BOM and packing list (item number, manufacturer part number, and quantity).
		Turnkey PCBasic offers complete turnkey PCB assembly, sourcing from reliable, authorized distributors only. We guarantee zero markup on component costs and confirm every purchase with you.
		Partial Turnkey You can supply key ICs or special components, and we’ll handle the rest. Our procurement team ensures cost efficiency, traceability, and quality consistency.
3	Assembly Options	We support SMT (Surface Mount Technology), DIP (Through-Hole Assembly), and Hybrid processes. Both single-side and double-side assemblies are available. Our selective soldering and nitrogen reflow systems ensure high reliability for complex assemblies.
4	Types of Solder	We provide both lead-free (RoHS compliant) and leaded soldering options. Nitrogen reflow ovens and selective wave soldering systems minimize oxidation and guarantee smooth, reliable joints.
5	Stencils	We use laser-cut stainless steel stencils with micron-level precision for fine-pitch and BGA components. Nano-coated stencils are available upon request for improved paste release and consistency.
6	Minimum Order	We welcome both prototype and small-batch orders, starting from as few as 5 pieces. Our flexible production system helps reduce cost while maintaining manufacturing efficiency.
7	Component Size	Passive Components Capable of mounting components down to 01005, 0201, 0402.
		BGA Supports 0.25 mm pitch with 3D X-Ray inspection.
		Fine-Pitch ICs Handles 0.25 mm fine-pitch parts with high precision placement.
8	Component Package	We accept components in Reel, Cut Tape, Tube, Tray, or Bulk Packaging. Loose parts are manually loaded by experienced operators when necessary.
9	Board Dimension	Min Size 50 mm × 100 mm (smaller boards should be panelized).
9	Board Dimension	Max Size up to 250 mm × 500 mm, supporting large industrial and control panels with special fixtures.
10	Board Shape	We can assemble Rectangular, Circular, and Custom/Odd-Shaped PCBs. For non-rectangular shapes, panelization with break-away rails is recommended to ensure automated machine assembly.
11	Board Type	PCBasic handles a wide range of board types including Rigid, Flex, and Rigid-Flex PCBs. You can upload your PCB file here: https://www.pcbasic.com/standard_pcb.html to get an instant quote.
12	Testing & Inspection	Every PCBA undergoes 3D AOI, SPI, X-Ray, Flying Probe, ICT, and Functional Testing (FCT). Full traceability through MES ensures zero-defect quality control.
13	Repair & Rework	We offer BGA reballing, component rework, and repair services using precise rework stations and X-ray alignment. This ensures cost-effective recovery of high-value boards.
14	Final Assembly (Box Build)	Beyond PCBA, we provide box build and system integration services, including mechanical assembly, cable harnessing, testing, labeling, and packaging, enabling true end-to-end delivery.
